Shrikant Steel Centre is a trusted Reducer Pipe Fittings Supplier in Dubai. Our Reducer Pipe Fittings are highly durable, robust, and precision-engineered. Our products can also be customized and machined to match the exact specifications required by our customers. We provide high-quality pipe reducers that strictly adhere to national and international raw material standards.
Shrikant Steel Centre is a leading Reducer Pipe Fittings Supplier in Dubai . We Suppliers Pipe Reducers using advanced production techniques backed by comprehensive quality assurance. To meet various industrial demands, we supply pipe reducers in a broad range of wall thicknesses, sizes, and schedules.Our pipe fitting reducers are designed to connect pipes of different diameters to regulate or transition flow. They are widely used across multiple sectors and are available in concentric and eccentric designs across Stainless Steel, Carbon Steel, and Alloy Steel grades.
| Reducer Pipe Fittings | Specification |
|---|---|
| Types | Concentric Reducer, Eccentric Reducer, Weld Reducer, Threaded Reducer, Socket Weld Reducer |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Size | ½ NB to 48NB (Seamless up to 24", Welded up to 48") |
| Form | Seamless / ERW / Welded / Fabricated |
| Grade | |
| Stainless Steel | 201, 202, 205. 301, 302, 303, 304, 304L, 308, 309, 309S, 310, 310S, 314, 316, 316L, 316TI, 317, 317L, 321, 347. 405, 409, 429, 430, 430F, 430FSe, 434, 436, 442, 446, 403, 410, 414, 416, 416Se, 420, 420F, 422, 431, 440A, 440B, 440C. 501, 502. 630 (17-4 PH). |
| Titanium | Titanium 6-4, Gr 1, Gr 2, Gr 3, Gr 4, Gr 5, Gr 7, Gr 9, 5-2.5, 6-2-4-2, 6-4 ELI, 6-6-2. |
| Hastelloy | C22, C276, X, B-2. |
| Monel | 400, K500. |
| Nickel Alloy | Nickel 200 Nickel 201, Alloy 20, Alloy 286, Alloy 218 (Nitronic 60), Nitronic 50 (XM-19). |
| Inconel | 601, 625, 660A, 718, X-750, 825, 925, 608. |
| Nimonic Alloy | 75, 80A, 81, 86, PE16, PE12. |
| Duplex / Super Duplex | D S31803, D S32205, SD S32750, SD S32760, SD S32950. |
The chemical composition of stainless steel reducer pipe fittings plays a essential role in determining their corrosion resistance, structural integrity, durability, and high-temperature performance. The following table highlights standard composition parameters for widely specified stainless steel grades. Specific requirements depend on the governing material standards.
| Stainless Steel Reducer Pipe Fittings Chemical Composition (%) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Type | C | Mn | P | S | Si | Cr | Ni | Mo |
| 304 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.00-20.00 | 8.00-11.00 | - |
| 304L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.00-20.00 | 8.00-13.00 | - |
| 310 | 0.25 max | 2.00 max | 0.045 max | 0.030 max | 1.50 max | 24.00-26.00 | 19.00-22.00 | - |
| 316 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| 316L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.00-18.00 | 10.00-15.00 | 2.00-3.00 |
| 317L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.00-20.00 | 11.00-15.00 | 3.00-4.00 |
| 321 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 17.00-19.00 | 9.00-12.00 | - |
Stainless steel reducer pipe fittings are engineered to offer optimal tensile strength, yield strength, ductility, and resistance to pressure deformation. Mechanical limits vary depending on material grade, heat treatment processes, and standard ASTM specifications.
| Stainless Steel Reducer Pipe Fittings Mechanical Properties | ||||
|---|---|---|---|---|
| Grade | UNS | Tensile Strength (ksi), min | Yield Strength (ksi), min | Elongation (%), min |
| WP304 | S30400 | 75 | 30 | 30 |
| WP304L | S30403 | 70 | 25 | 30 |
| WP316 | S31600 | 75 | 30 | 30 |
| WP316L | S31603 | 70 | 25 | 30 |
Reducer pipe fittings are supplied across various nominal pipe sizes, wall thicknesses, and schedules. The table below outlines nominal pipe sizes with corresponding outside diameters for quick reference.
| Reducer Pipe Fittings Size Chart | ||
|---|---|---|
| NPS (Nominal Pipe Size) | Outside Diameter (inches) | Outside Diameter (mm) |
| 1/8 | 0.405 | 10.29 |
| 1/4 | 0.540 | 13.72 |
| 3/8 | 0.675 | 17.15 |
| 1/2 | 0.840 | 21.34 |
| 3/4 | 1.050 | 26.67 |
| 1 | 1.315 | 33.40 |
| 1 1/4 | 1.660 | 42.16 |
| 1 1/2 | 1.900 | 48.26 |
| 2 | 2.375 | 60.33 |
| 2 1/2 | 2.875 | 73.03 |
| 3 | 3.500 | 88.90 |
| 3 1/2 | 4.000 | 101.60 |
| 4 | 4.500 | 114.30 |
| 5 | 5.563 | 141.30 |
| 6 | 6.625 | 168.28 |
| 8 | 8.625 | 219.08 |
| 10 | 10.750 | 273.05 |
We are a leading High Quality Reducer Pipe Fittings Supplier in Dubai
Our several locations in Dubai make it easier for our customers to purchase from Shrikant Steel Centre regardless of where they are. When you require high-quality Reducer Pipe Fittings and other related components at a competitive price, contact us to ensure prompt and reliable delivery.
| City We Supply | |||||
|---|---|---|---|---|---|
| Bengaluru | Mumbai | Chennai | Hyderabad | Kolkata | Pune |
| New Delhi | Ahmedabad | Jaipur | Surat | Salem | Gandhinagar |
| Bhiwandi | Tiruppur | Sivakasi | Jamnagar | Thiruvananthapuram | Rajahmundry |
| Bhubaneswar | Vijaywada | Firozabad | Pithampur | Rajkot | Bharuch |
| Panna | Raipur | Cochin | Ludhiana | Panipat | Durgapur |
| Peenya | Hosdurg | Channapatna | Kharagpur | Nashik | Bareilly |
Shrikant Steel Centre is a renowned Reducer Pipe Fittings Supplier. Every year, significant quantities of reducer pipe fittings are exported globally. We deliver to clients worldwide with consistent commitment to quality and quick turnaround times.
| Countries We Supply | ||||
|---|---|---|---|---|
| Saudi Arabia | Oman | Kuwait | Netherlands | Iran |
| Bahrain | Qatar | UAE | Africa | China |
| Nigeria | Mexico | Canada | Venezuela | United Kingdom |
| United States | South Africa | Malaysia | Bangladesh | Turkey |
| Singapore | Sri Lanka | Australia | Brazil | Germany |
| France | Italy | South Korea | Poland | Belgium |
