Shrikant Steel Centre is a trusted Stub Ends Lap Joint Supplier in Dubai. We supply high-quality lap joint stub ends designed for reliable connections in industrial piping systems. Our products are available in different sizes, schedules, material grades, and dimensions to meet project requirements.
Shrikant Steel Centre is a reliable Stub Ends Lap Joint Supplier in Dubai , providing high-performance components for industrial piping systems. Designed for butt-weld connections, these stub ends are paired with lap joint flanges to allow easy flange rotation and quick bolt-hole alignment during installation. To meet diverse project specifications, products are available in both long-pattern and short-pattern configurations across various dimensions and wall thicknesses. They supply stub ends in stainless steel, carbon steel, alloy steel, duplex steel, and special alloys tailored to project demands.
| Stub Ends Lap Joint | Specification |
|---|---|
| Types | Long Pattern Stub Ends, Short Pattern Stub Ends, Type A Stub Ends, Type B Stub Ends, Butt Weld Stub Ends, Lap Joint Stub Ends |
| Standards | ASME B16.9, MSS SP-43, ASTM A403, ASTM A234, ASTM A815, and other applicable specifications depending on material and product type |
| Schedule | SCH 5S, SCH 10S, SCH 10, SCH 20, SCH 40, STD, SCH 80, SCH 80S, XS, SCH 120, SCH 160, XXS, subject to size and material availability |
| Size | 1/2 NB to 48 NB, depending on applicable standards, production methods, and project requirements. |
| Pattern | Long Pattern and Short Pattern |
| End Connection | Butt Weld End with Lap Joint Flange Compatibility |
| Form | Seamless, Welded, and Fabricated, subject to product type and specification |
| Grade | |
| Stainless Steel | 201, 202, 205. 301, 302, 303, 304, 304L, 308, 309, 309S, 310, 310S, 314, 316, 316L, 316Ti, 317, 317L, 321, 347. 405, 409, 429, 430, 430F, 434, 436, 442, 446, 403, 410, 414, 416, 420, 422, 431, 440A, 440B, 440C. 630 (17-4 PH), subject to product form and applicable specification. |
| Carbon Steel | ASTM A234 WPB, ASTM A420 WPL6, and other applicable carbon steel grades. |
| Alloy Steel | ASTM A234 WP5, WP9, WP11, WP12, WP22, WP91, and other applicable alloy steel grades. |
| Titanium | Grade 1, Grade 2, Grade 3, Grade 4, Grade 5, Grade 7, Grade 9, and other grades subject to availability. |
| Hastelloy | C22, C276, X, B-2. |
| Monel | 400, K500. |
| Nickel Alloy | Nickel 200, Nickel 201, Alloy 20, Alloy 286, Nitronic 50 (XM-19), Nitronic 60 (Alloy 218). |
| Inconel | 600, 601, 625, 718, X-750, 800, 800H, 825, 925. |
| Nimonic Alloy | 75, 80A, 81, 86, PE16, PE12. |
| Duplex / Super Duplex | UNS S31803, S32205, S32750, S32760, and other grades subject to requirements. |
The chemical composition of stainless steel lap joint stub ends determines their corrosion resistance, strength, weldability, and suitability for different operating environments. The following table provides typical composition limits for commonly used stainless steel grades. Actual chemical requirements depend on the material specification, product form, and applicable standard.
| Stainless Steel Stub Ends Lap Joint Chemical Composition (%) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Type | C | Mn | P | S | Si | Cr | Ni | Mo |
| 304 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.00-20.00 | 8.00-10.50 | - |
| 304L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.00-20.00 | 8.00-12.00 | - |
| 310 | 0.25 max | 2.00 max | 0.045 max | 0.030 max | 1.50 max | 24.00-26.00 | 19.00-22.00 | - |
| 316 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| 316L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| 317L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.00-20.00 | 11.00-15.00 | 3.00-4.00 |
| 321 | 0.08 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 17.00-19.00 | 9.00-12.00 | - |
Stainless steel lap joint stub ends are selected according to their strength, ductility, corrosion resistance, and suitability for welding. Mechanical properties vary by grade, product form, heat treatment, and specification. The following values are indicative references for commonly used wrought stainless steel grades. Confirm acceptance requirements against the applicable product standard.
| Stainless Steel Stub Ends Lap Joint Mechanical Properties | ||||
|---|---|---|---|---|
| Grade | UNS | Tensile Strength (ksi), min | Yield Strength (ksi), min | Elongation (%), min |
| 304 | S30400 | 75 | 30 | 30 |
| 304L | S30403 | 70 | 25 | 30 |
| 316 | S31600 | 75 | 30 | 30 |
| 316L | S31603 | 70 | 25 | 30 |
Lap joint stub ends are available in various nominal pipe sizes and in long-pattern and short-pattern configurations. Their dimensions include barrel outside diameter, overall length, lap diameter, and fillet radius. The chart below provides selected reference dimensions in millimetres based on ASME B16.9 dimensional tables. Final dimensions and tolerances should be confirmed against the applicable standard and purchase specification.
| Stub Ends Lap Joint Dimensions Chart (mm) | ||||||
|---|---|---|---|---|---|---|
| NPS | Barrel OD Max. | Barrel OD Min. | Long Pattern Length (F) | Short Pattern Length (F) | Fillet Radius (R) | Lap Diameter (G) |
| 1/2 | 22.8 | 20.5 | 76 | 51 | 3 | 35 |
| 3/4 | 28.1 | 25.9 | 76 | 51 | 3 | 43 |
| 1 | 35.0 | 32.6 | 102 | 51 | 3 | 51 |
| 1 1/4 | 43.6 | 41.4 | 102 | 51 | 5 | 64 |
| 1 1/2 | 49.9 | 47.5 | 102 | 51 | 6 | 73 |
| 2 | 62.4 | 59.5 | 152 | 64 | 8 | 92 |
| 2 1/2 | 75.3 | 72.2 | 152 | 64 | 8 | 105 |
| 3 | 91.3 | 88.1 | 152 | 64 | 10 | 127 |
| 3 1/2 | 104.0 | 100.8 | 152 | 76 | 10 | 140 |
| 4 | 116.7 | 113.5 | 152 | 76 | 11 | 157 |
| 5 | 144.3 | 140.5 | 203 | 76 | 11 | 186 |
| 6 | 171.3 | 167.5 | 203 | 89 | 13 | 216 |
| 8 | 222.1 | 218.3 | 203 | 102 | 13 | 270 |
| 10 | 277.2 | 272.3 | 254 | 127 | 13 | 324 |
| 12 | 328.0 | 323.1 | 254 | 152 | 13 | 381 |
Lap joint stub ends are used in piping systems where flange rotation, convenient alignment, and simplified maintenance are important. They are commonly installed with lap joint flanges in systems that require frequent dismantling or use corrosion-resistant piping materials. The appropriate stub end and flange combination depends on pressure, temperature, fluid compatibility, material grade, and applicable piping standards.
We are a leading High Quality Stub Ends Lap Joint Supplier in Dubai
Our supply network helps customers across Dubai source quality stub ends lap joint fittings for industrial piping projects. Shrikant Steel Centre supplies different material grades, sizes, and configurations according to customer requirements. Contact us for product specifications, availability, and delivery details.
